440w bifacial solar panel,home sue bifacial solar panels

Type
PERC, Half Cell, Bifacial, Double-glass, Half Cell
Panel Efficiency
420W~460W
Warranty
5years
Solar cell
Mono 166*166 Cell
Cell size
166mmx166mm
Project Type
Design, Supply And Installation.

Produt Details

Bifacial solar panel 440w 445w 450w 455w 460w solar panel power

Double-sided solar cells, this new type of solar cell can be used on both sides at the same time, thereby effectively improving the power generation efficiency. Among the traditional solar cells, the monocrystalline silicon cell has the highest light conversion efficiency, up to about 19%, which is more efficient for power conversion, and this new type of double-sided solar cell can further increase the light conversion efficiency to 20%-30% .

Module Type	AS-6M 144-BHC-435W~455W
Maximum Power(Pmax)	435W	440W	445W	450W	455W
Open Circuit Voltage(Voc)	49.6V	49.8V	50.0V	50.2V	50.4V
Short Circuit Current(Is c)	11.10A	11.16A	11.22A	11.28A	11.34A
Voltage at Maximum Power(Vmp)	41.2V	41.4V	41.6V	41.8V	42.0V
Current at Maximum Power(Imp)	10.56A	10.63A	10.70A	10.77A	10.84A
Module Eff ciency(%)	20.0	20.2	20.4	20.7	20.9
Operating Temperature	-40°C to+85℃
Maximum System Voltage	1500V(IEC)
Fire Resistance Rating	Class C
Maximum Series Fuse Rating	20A
*STC Irradiance1000W/m², Cell temperature 25C, AM 1.5; Tolerance of Pmax:±3%; Measurement Tolerance:±3%

At the same time, the power generation efficiency of a single cell has also been improved from 4 watts to 4.5 watts of traditional batteries to 4.5 watts to 6 watts. With the increasingly intensified contradiction between resource supply and demand, the further development and utilization of solar energy will definitely become the future development trend, and this product has opened up a good development idea. At present, double-sided solar panels are used in many solar energy systems in the United States.

Our Project：

Our company's solar energy projects are mainly located in Asia, the Middle East, and the Americas. Whether in commercial or domestic solar installations, there are successful cases of installation and use.

Packing & Delivery：

Our solar panels are packaged and transported in wooden pallets and cartons, and each solar panel is protected at the edges and corners to prevent damage. If you have special product packaging requirements, you can send an inquiry to contact us

Company Profile：

As a leader in solar power station, NAMKOO POWER is committed to building high-quality solar power station and setting up industry benchmarks, providing users quality services and safely Tailor-made engineering solutions as well as money for a long time.

We provide systematic bank financing plan and full range of insurance for each customer to protect their income.

NAMKOO POWER adheres to the goal of building a quality power station. Through global channels, technological means and continuous research and development innovation capabilities, NAMKOO POWER strives to make greater contributions to the development of global clean energy, the improvement of people's quality of life, and the construction of blue sky.
