New Upgrade Lithium Battery 6‐GFM‐200/12V200Ah

Battery Model
6‐GFM‐200/12V200Ah
Internal Resistance
5.0mΩ
Max Discharge Current
1702A(3 Sec.)
Self Discharge
≤2% per month (25℃)

Produt Details

Selling point of 12V 200Ah Lithium Battery Pack:

1.Wide operating temperature range from ‐25°C to 45°C.
2.Sealed and maintenance free operation.
3.Low self‐discharge rate and long shelf life (9 months at 25°C).
4.ABS containers and covers.
5.No memory effect, thick flat plate with high Tin low Calcium alloy.
6.Absorptive Glass Mat Technology (AGM System).
7.Safety valve installation for explosion proof.
8.Long Service Life, Float or Cyclic.

Battery Model	6‐GFM‐200/12V200Ah
Capacity (25℃)	10Hr（20A,1.80V）	5Hr(34A,1.80V)	3Hr（50A,1.80V）	1Hr(110A,1.80V)

	200Ah	170Ah	150Ah	110Ah
Dimensions	Length	Width	Height	Total Height

	521mm	240mm	220mm	220mm
Internal Resistance	5.0mΩ
Max Discharge Current	1702A(3 Sec.)
Self Discharge	≤2% per month (25℃)
Charge Voltage 25℃	Cycle Use		Float Use
	13.98V(‐24mV/℃),max charge current:40A		13.38V(‐21mV/℃)

12V 200Ah Lithium Battery Pack PROJECT SERVICE PROCESS

(1) PROJECT CONSULTATION.	(2) THE PROJECT SURVEY.	(3) PROJECT DESIGN.
Product introduction, process explanation, investment budget analysis.	Engineers site roof survey, load measurement, shielding analysis, electrical building path planning.	According to the survey results, the optimal system design scheme and grid connection scheme are formulated to escort the high-quality power station.
(4) APPLICATION.	(5) PROVIDE COMPLETE EQUIPMENT.	(6) OVERSEAS OPERATION, MAINTENANCE AND SERVICE GUARANTEE.
Responsible for preparing the application materials and connecting to the network.	According to the design to provide photovoltaic panel, inverter, bracket and other complete set of material equipment.	Professional construction, grid acceptance, operation and maintenance, intimate after-sales service.

Namkoo Project Service Process

ABOUT NAMKOO

Namkoo Group is an international high-technology and fast growing group company, we specializing in R&D, manufactures on grid and off grid solar power system, hybrid solar storage system, mono solar panel, poly solar panel, flexible solar panel, Shingled & HJT Solar Panel, solar inverter & battery, and other solar applications. With more than 18 years solar experience, Namkoo is aiming to become “Your Best Collaborate Solar Manufacturer”.

Apart from the traditional solar panel, battery, solar power system and solar pump system products, we have researched and offered successful advanced solar application including BIPV solar projects, solar carport charger station, IOT + solar products like A.I. solar bus station and A.I. PV waste sorting kiosk, etc.

eight steps to produce solar panel

Namkoo has distributed 97 patents. The distribution of invention patents accounted for 29%, and the issued patents accounted for 65%. 14 software Copyrights have been distributed, of which 100% have been issued.

The patent application covers waterproof, corner, flexible, controllable temperature, fault identification, adjustable, intelligent, high power, high density and other functional and technical highlights, covering the core photovoltaic power station, photovoltaic vehicle, photovoltaic bracket, photovoltaic tile, photovoltaic building, sun room, cloud broadcasting, charging pile, storage device, photovoltaic street lamps and other products. Involving multiple grid, PERC, buckle, mechanical plug type and other key technology, process.

The 14 software Copyrights form the intellectual property protection of core system technologies such as photovoltaic power station monitoring system, cloud broadcasting system, atmospheric environment monitoring system, motor operation monitoring system, water quality monitoring system, intelligent water system, intelligent fire protection system, intelligent bus station air monitoring system.

Namkoo Team
