PWM Solar Charge Controller For Solar Energy System
  • PWM Solar Charge Controller For Solar Energy System
  • PWM Solar Charge Controller For Solar Energy System
  • PWM Solar Charge Controller For Solar Energy System

PWM Solar Charge Controller For Solar Energy System

  • Rated charging current

    50A
  • Rated system voltage

    384V
  • Number of PV array input routes

    1
  • PV Array Maximum Power

    22.4KW
  • Floating voltage

    13.8V/Single battery
  • Charge voltage

    14.2V/Single battery
  • Charging protection voltage

    15V/Single battery

Produt Details

PRODUCT: PWM Solar Charge Controller.

MODEL: KY1-PWM



SELLING POINTS of PWM Solar Charge Controller:

1.Excellent performance because of an MCU intelligent control technology.
2.Visualization of operation status of the equipment through Chinese and English menus, LEDs and an LCD.
3.Solar array, battery common-anode system input and multiple independent solar array input control.
4.Settable battery protection parameters.
5.Display of the current battery voltage, battery charge current, internal temperature of the case, total photovoltaic power.
generation capacity, total power consumption by the load, photovoltaic current when each solar array is separately charged.
6.Overall protection: protection an alarm for reverse connection of the battery poles, battery overcharge, cooling control for
interior of the cabinet (the fan will be started upon 45°C) and back charge of the battery at night.
7.Function of historical records and password protection.
8.Function of clock display.



KY1  Parameter
Rated charging current 50A 100A
Rated system voltage 384V 192V/216V/240V/384V
PV input voltage range 192V System:240V-352V;216V System:270V-396V;240V System:300V-440V;384V System:480V-704V
Max PV Input Voltage(At 25℃) 192V System:400V;216V System:450V;240V System:500V;384V System:750V
Number of PV array input routes 1
PV Array Maximum Power 22.4KW 22.4KW/25.2KW/28KW/44.8KW
Battery type Lead acid battery, deep cycle battery, gel battery etc(Battery type base on user charge specification)
Floating voltage 13.8V/Single battery
Charge voltage 14.2V/Single battery
Charging protection voltage 15V/Single battery
Temperature compensation coefficient -3mV / ℃ / 2V (25℃  is base line )(Optional)
Charging mode PWM pulse width control
Charging method Three stages :constant current; constant voltage; floating charge
Efficiency >95%
Display LCD
Cooling method Cooling fan in intelligent control
Type of mechanical protection IP20
Operating temperature -20℃~+60℃
Storage  temperature -20℃~+70℃
Elevation <5000m,(Less solar panel when exceed 2000m)
Humidity 5~95%(No condense)
Protect the circuit RS232/RS485(Optional)
Machine size (L*W*Hmm) 460*360*160
Package size (L*W*Hmm) 530*405*225
N.W (Kg) 9 10
G.W (Kg) 11 12





Solar Charge Controller for sale

Solar Charge Controller







PWM Solar Charge Controller PROJECT SERVICE PROCESS


(1) PROJECT CONSULTATION. (2) THE PROJECT SURVEY. (3) PROJECT DESIGN.
Product introduction, process explanation, investment budget analysis. Engineers site roof survey, load measurement, shielding analysis, electrical building path planning. According to the survey results, the optimal system design scheme and grid connection scheme are formulated to escort the high-quality power station.
(4) APPLICATION. (5) PROVIDE COMPLETE EQUIPMENT. (6) OVERSEAS OPERATION, MAINTENANCE AND SERVICE GUARANTEE.
Responsible for preparing the application materials and connecting to the network. According to the design to provide photovoltaic panel, inverter, bracket and other complete set of material equipment. Professional construction, grid acceptance, operation and maintenance, intimate after-sales service.
